AC1200 Wireless VDSL/ADSL Modem Router

Archer VR300

Popis

• Parental Controls: manage responsible internet access for your children
• Guest Network|: provides separate access for guests while securing the home network
• Firewall Security: supports DoS, SPI Firewall, IP Addressing/Domain Filter, IP/MAC Address Binding
• Quality of Service: prioritizes network traffic by device or application
• IPTV IGMP Proxy/Snooping: supports Bridge and Tag VLAN for smooth IPTV application
• IPv6: compatible with IPv6 (Internet Protocol version 6)
• Multilingual Interface: provides hassle-free configuration in six languages (EN/DE/IT/TR/RU/PO)

Technická specifikace

HARDWARE FEATURES

Interface

• 3 10/100 RJ45 LAN Ports
• 1 10/100 RJ45 LAN/WAN Port
• 1 RJ11 Port

Button

• WPS Button
• Power On/Off Button
• Reset Button

Power Supply

• 12VDC/1A

VDSL2 Standards

• ITU G.993.2, Up to 17a pro¬le (POTS)
• ITU-T G.993.5 (G.vector)
• ITU-T G.998.4 (G.INP)

ADSL Standards

• Full-rate ANSI T1.413 Issue 2,
• ITU-T G.992.1(G.DMT),
• ITU-T G.992.2(G.Lite),
• ITU-T G.994.1 (G.hs),
• ITU-T G.995.1

ADSL2 Standards

• ITU-T G.992.3 (G.DMT.bis),
• ITU-T G.992.4 (G.lite.bis)

ADSL2+ Standards

• ITU-T G.992.5

Dimensions ( W x D x H )

• 385*290*76mm

Antenna Type

• 4 fixed external antennas

WIRELESS FEATURES

Wireless Standards

• IEEE 802.11a/n/ac 5GHz,
• IEEE 802.11b/g/n 2.4GHz

Wireless Speeds

• 867Mbps at 5GHz
• 300Mbps at 2.4GHz

Transmit Power

• 2.4GHz <20dBm(EIRP)
• 5GHz <23dBm(EIRP)

Wireless Functions

• Access Point / Wireless Bridge, Wireless Enable\Disable, SSID Broadcast Enable\Disable

Wireless Security

• WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, QSS(WPS)

SOFTWARE FEATURES

Quality of Service

• ATM QoS, Bandwidth Control

Security

• NAT Firewall, Access Control, IP and MAC Address Binding

Operating Modes

• VDSL/ADSL Modem Router, Wireless Router

Management

• Web Based Con¬guration(HTTP), Remote management,

command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware

• Upgrade, Diagnostic Tools

DHCP

• Server, Client, DHCP Client List, Address Reservation, DHCP Relay

Port Forwarding

• Virtual Server, Port Triggering, DMZ, ALG, UPnP

Dynamic DNS

• DynDns, NO-IP

VPN Pass-Through

• PPTP, L2TP, IPSec Passthrough

Protocols

• Supports IPv4 and IPv6

ATM/PPP Protocols

• ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364),

PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483
Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
Advanced Functions

• Parental Control, Network Address Translation(NAT),
• Port Mapping(Grouping), Static Routing, RIP v1/v2(optional), DNS Relay,
• DDNS, IGMP V1/V2/V3

Guest Network

• 2.4GHz guest network, 5GHz guest network

OTHERS

Certification
CE, RoHS, RCM
Package Contents ·

• AC1200 Wireless VDSL/ADSL Modem Router Archer VR300
• External Splitter
• RJ11 DSL Cable
• RJ45 Ethernet Cable
• Power Adapter
• Quick Installation Guide

System Requirements

• Microsoft Windows XP/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
• Internet Explorer, Firefox, Chrome, Safari or other Java-enabled browser
• Subscription with an Internet Service Provider (for Internet access)

Environment

• Operating Temperature: 0?~40? (32? ~104?)
• Storage Temperature: -40?~70? (-40? ~158?)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
